Great Zimbabwe, Zimbabwe, 2024

Scope of Supply: Francis Turbines (2x 6,25 m³/s) Generators, Inlet Valve, Hydraulic Power Units, Auxiliary System, Switchgears, Control System, Transformers

Number of Units
2
Total Output (kW)
5 400
Head of water (m)
47,5
Flow (m3/s)
6,3
Runner Diameter (mm)
980

Moco Moco, Guyana, 2024

Scope of Supply: Pelton Turbines (2x 0,22 m³/s), Generator, Flywheel, HPU, Inlet Valve, Control & Protection Equipment, Switchgear, Auxiliary Supply System

Number of Units
2
Total Output (kW)
787
Head of water (m)
206,9
Flow (m3/s)
0,2
Runner Diameter (mm)
488

Obuse, Japan, 2018

Scope of Supply: Francis Turbine, Generator, Butterfly Valve, Hydraulic Power Unit, Control System

Number of Units
1
Total Output (kW)
196
Head of water (m)
14,4
Flow (m3/s)
1,5
Runner Diameter (mm)
620

Juan Garcia, Colombia, 2016

Scope of Supply: Pelton Turbines, Generators, Butterfly Valves, Hydraulic Power Unit, Control- and Protection-System

Number of Units
2
Total Output (kW)
4 710
Head of water (m)
264,0
Flow (m3/s)
1,0
Runner Diameter (mm)
1 090

Hintergössgraben, Austria, 2017

Scope of Supply: Turbine, Generator, Inlet Valve, HPU, Bifucation Pipe

Number of Units
1
Total Output (kW)
1 035
Head of water (m)
111,9
Flow (m3/s)
1,1
Runner Diameter (mm)
711

Bodorna, Georgia, 2018

Scope of Supply: Turbine, Generator, Hydraulic Power Unit, Control System, SCADA, Medium Voltage System, Transformer, Diesel Generator

Number of Units
1
Total Output (kW)
2 556
Head of water (m)
8,1
Flow (m3/s)
32,0
Runner Diameter (mm)
2 240

Yarucaya, Peru, 2014

Scope of Supply: Francis Turbine, Butterfly Valve, Maintenance Valve, Singer Pressure Sustaining Valve, Y-Manifold, HPU, Generator, Electrical Switchgears, Control & Protection Systems, SCADA, Transformers

Number of Units
2
Total Output (kW)
18 068
Head of water (m)
168,9
Flow (m3/s)
6,0
Runner Diameter (mm)
900

Marañon, Peru, 2015

Scope of Supply: Francis Turbine, Butterfly Valve, HPU, Generator, all Electrical Switchgears, Control & Protection Systems, SCADA, Transformers

Number of Units
3
Total Output (kW)
19 683
Head of water (m)
84,5
Flow (m3/s)
8,7
Runner Diameter (mm)
1 115

Muara, Indonesia, 2016

Scope of Supply: Francis Turbine, Butterfly Valve, HPU, Generator, Control & Protection Systems, Station Service Transformer

Number of Units
2
Total Output (kW)
2 242
Head of water (m)
94,0
Flow (m3/s)
1,3
Runner Diameter (mm)
460
